3D Visualization
Brief
Luxury Pool-Level Office & Reception — Munnar, Kerala
We need photorealistic 3D interior renders for a ground-floor office space located directly beneath a figure-8 infinity pool. The space features curved sliding glass doors opening to the Munnar valley, dark marble finishes with brushed gold accents, and warm ambient LED lighting throughout.
Stayezy Office & Reception
Project
Stayezy Office & Reception
Location
Chithirapuram, Near Anachal, Munnar, Kerala
Space Type
Commercial office under residential infinity pool
Design Theme
Dark marble + brushed gold + warm LED + wood slat paneling
Floor Area
~45 sq.m (approx)
Ceiling Height
3.05 m (10 ft)
Front Facade
6 curved/straight sliding glass door bays (18.39m total)
What's Inside
A detailed breakdown of the office space, divided into left and right sections from the entrance.
Left Side
Reception Area
Central to the space
- ◆ Dark marble reception counter with brushed gold wave accent on front
- ◆ Wood slat paneling on back wall behind Stayezy logo
- ◆ LED-backlit logo with gold lettering
- ◆ 4 decorative pendant lights (matte black + gold)
- ◆ Recessed ceiling cove with LED strip
- ◆ LED strip under desk (indirect glow)
- ◆ iMac / computer setup on counter
- ◆ Guest-facing USB-C charging point
Lounge / Sofa Area
Left side near P1 glass bay
- ◆ Comfortable sofa seating
- ◆ Accent downlights
- ◆ View through Bay 1 and Bay 2 curved glass to the valley
WC Left
Back wall, left corner — 2700 x 1200 mm
- ◆ Full dark marble walls and floor
- ◆ LED-backlit mirror
- ◆ Floating vanity with brushed gold front panel and LED underside glow
- ◆ 2 pendant lights (matte black cylindrical)
- ◆ Wall-mounted WC
- ◆ Wood slat storage cabinet
Right Side
Manager Cabin
Right-centre area
- ◆ Dark marble desk with brushed gold sculptural legs
- ◆ Backlit display shelves with LED strips (books, decor)
- ◆ 3-light linear pendant bar (brushed gold)
- ◆ Executive chair + visitor seating area
- ◆ View through Bay 5 glass to the valley
WC Right
Back wall, right side — 2700 x 1200 mm
- ◆ Same design as WC Left (dark marble, gold vanity, LED mirror)
- ◆ Symmetrical to left WC
Pump Room
Back wall, far right corner — 1450 x 2380 mm
- ◆ Technical/utility room
- ◆ Does not need rendering unless vendor wants to show it closed
Measurements
All dimensions provided for accurate 3D modeling. Refer to the floor plan above.
Overall Space
Columns
Depth
Front Pillars (P1 to P5) — Glass Between Each
| Bay | Position | Shape | Glass Width |
|---|---|---|---|
| Bay 1 | Left Wall → P1 | Straight | 3,340 mm |
| Bay 2 | P1 → P2 | Curved | 4,160 mm |
| Bay 3 | P2 → P3 | Curved | 2,730 mm |
| Bay 4 | P3 → P4 | Curved | 2,330 mm |
| Bay 5 | P4 → P5 | Curved | 3,450 mm |
| Bay 6 | P5 → Right Wall | Straight | 2,380 mm |
| Total | 18,390 mm | ||
Internal Rooms (on back wall)
Horizontal Centre Distances
Reference Images
Mood board and reference visuals to guide the 3D visualization style and atmosphere.
Reference 1
Reception Area Render
Dark marble counter, Stayezy logo, gold wave accent, pendant lights, wood slat wall
Reference 2
Manager Cabin Render
Dark marble desk, gold legs, backlit shelves, pendant bar, executive chair
Reference 3
WC Render
Full dark marble, LED mirror, gold vanity, wood slat cabinet, pendant lights
Reference 4
Floor Plan
The SVG structural plan with all measurements
Reference 5
Pool Exterior
Figure-8 pool from above (to show context)
Reference 6
Front Elevation
Curved glass between pillars with pool above
Reference images available on request. Contact us for high-resolution files.
What We Need
Required Renders
Reception area — front view (showing counter, logo wall, pendant lights)
Reception area — wide angle from glass door side (showing full space depth)
Manager cabin — front view (desk, shelves, pendant bar)
Manager cabin — side angle (showing glass bay view)
WC — one full interior render (mirror, vanity, WC)
Full space — panoramic/wide angle showing entire ground floor
Exterior view — looking in through curved glass doors (showing interior visible through glass)
Optional Add-ons
Quote these separately if available
File Format
High resolution PNG/JPEG (min 4000px wide) + source files (3ds Max / SketchUp / Blender)
Send Us Your Quote
Fill in the details below. We'll review all submissions and respond within 48 hours.
Important Notes
This is a Request for Quotation only, not a confirmed order
Reference images and AutoCAD plans available on request
Site visit can be arranged for shortlisted vendors
All renders must be original work, not AI-generated
Source files to be provided along with final renders
Payment: 50% advance, 50% on final delivery (negotiable)
